ELPESPEC® Auxiliary Products

ELPESPEC® Auxiliary Products can be used universally in the processing of any kind of coating material: They simplify and facilitate the application of circuit printing inks, conformal coatings and casting compounds in electronics manufacturing.

For circuit printing we offer universal products such as thinners and retarders, screen openers and antistatic sprays for screen printing, besides specific auxiliaries for processing photoimageable coating materials such as Stouffer grey step wedges, defoamants or special strippers.

Flow Cups for Determination of Viscosity (Flow Time)

  • Dip Cup acc. to DIN 53211, 4 mm nozzle
  • Polyamide cup with stainless steel nozzle
  • for a fast approximate determination of coating viscosity for roller coating, curtain coating or spray application
  • easy to handle
  • ideal for production and incoming goods inspection

Universal thinner UV 5000 / universal retarder UZ 5100

  • For many 1- and 2-pack screen printing inks if no dedicated thinner or retarder is specified
  • UV 5000 reduces the viscosity
  • UZ 5100 reduces the viscosity and prolongs the screen-open time

Universal thinner Methoxypropanol (PM)

  • Semi-volatile solvent with good solving capacity for many coating materials
  • used for thinning or cleaning
  • specified and certified quality

Universal thinner Methoxy propyl acetate (PMA)

  • Semi-volatile solvent without hydroxyl groups with good dissolving capacity for many coating materials
  • used for thinning or cleaning
  • specified and certified quality

Anti-static spray HP 5500

  • Prevents and removes static build-up in the pcb printing process
  • reduces dust-related errors in screen printing and when processing dry resists
  • highly effective, simple and safe to use
  • in a practical spray can

Screen opener HP 5200

  • Spray to dissolve dried printed circuit coatings from screens, no need for complicated washing proceses to clean screens after work breaks
  • highly effective, fast action
  • silicone- and grease-free, thus no occurrence of surface defects/dewettings or smearing in the subsequent printing process

Cleaning agent R 5899

  • For use in automatic screen washers, extremely high flash point (> 100 °C)
  • low vapour pressure < 0.1 hPa at 20 °C, thus no VOC (Volatile Organic Compound) per the EU directive 1999/13/EC
  • not classified according to CLP Regulation (EC) no. 1272/2008, easily biodegradable in acc. with OECD Test 301 A

Cleaning agent R 5800 series

  • Fast and intensive cleaning effect
  • R 5814/R 5817: Removes coatings from screens, tools and after print errors; R 5814 is lower in odour than R 5817 while R 5817 has a quicker cleaning effect
  • R 5821: High flash point (+32 °C), suitable for use in automatic screen washers and for cleaning ink processing equipment

Stouffer grey step wedge for the exposure of photoimagable coating materials

  • Stouffer 21-step wedge / grey step wedge
  • Polyester strips with different accurately defined density steps
  • for determination of exposure parameters

Defoamant HP 5911

  • For defoaming aqueous-alkaline developer solutions, e.g. 1% soda solution
  • silicone-free; biodegradable

Special stripper HP 5710

  • Suitable for removing exposed or, if necessary, cured photoimageable solder resists (e.g. after incorrect exposure)
  • suitable for cleaning coating developers and resist stripper equipment, prepared quantity can be used multiple times

Touch-up coatings / repair coatings: Touch-up lacquer SD 2369 UV-ABL

  • Application by screen printing or brush
  • yellow-green 1-pack coating
  • UV curing
  • auxiliary products recommended: Anti-static spray HP 5500, Cleaning agents R 5899, R 5821 and R 5817

Touch-up coatings / repair coatings: Repair coating EH 13.767

  • Application by brush
  • Green opaque, mat 1-pack coating
  • Dries at room temperature, beneficial for the repair of pcb assemblies after completed soldering as they often must not be exposed to further thermal stress
  • Recommended auxiliary product: Cleaning agent R 5817

Conductive ink EH 13.344

  • Applied as a coating on the inside of casings and packagings, it prevents and diverts static charges
  • application by brushing or spraying
  • dries at room temperature
  • auxiliary product recommended: Cleaning agent R 5817

The assembler will find practical aids such as peelable solder masks from the squeeze bottle for partially covering assembled printed circuit boards in wave soldering processes, dosing accessories for applying dam and fill gels, or flow cups for adjusting the processing viscosity.

Peelable Solder Masks of the series PEEL OUT

  • For the partial covering of assembled PCBs undergoing wave soldering
  • easy application from the handy squeeze bottle, ready-to-use
  • dries at room temperature
  • peelable

Flow Cups for Determination of Viscosity (Flow Time)

  • Dip cup acc. to DIN 53211: polyamide cup with 4 mm stainless steel nozzle
  • for a fast approximate determination of conformal coating viscosity
  • easy to handle
  • ideal for production and incoming goods inspection

Dosing accessories for the application of dam-and-fill gels

  • Dispensing pistol and dispensing needles fitting the 30 and 55 ml cartridges of ELPEGUARD dam-and-fill gels
  • standard dispensing needle no. 14, Ø 1.60 mm
  • standard dispensing needle no. 18, Ø 0.84 mm
  • standard dispensing needle no. 22, Ø 0.41 mm
  • standard dispensing needle 45° curved, no. 16, Ø 1.65 mm

Cleaning agent R 5817

  • cleaning agent for conformal coatings, thick film coatings and gels (if no dedicated cleaning agent is specified in the Technical Report)
  • for cleaning of workplace, tools and coating units; rapid and intensive cleaning effect

Cleaning agent R 5807

  • cleaning agent for moisture crosslinking silicone coatings
  • for cleaning of coating units; rapid and intensive cleaning effect

Cleaning agent R 5851

  • for removing solder residues from assembled pcbs

Cleaning agent R 5888

  • For the reliable removing of conformal coatings from carriers, e.g. ELPEGUARD conformal coatings based on acrylate/polyurethane/epoxy resins
  • high performance
  • aqueous, biodegradable
  • high user safety

Conductive ink EH 13.344

  • Applied as a coating on the inside of casings and packagings it prevents and diverts static charges
  • application by brushing or spraying
  • dries at room temperature
  • auxiliary product recommended: Cleaning agent R 5817

Sealing mastic for sealing work prior to potting, grip agents to improve the adhesion, mould release agents, accelerating agents, cleaning agents and many more products to aid in the processing of casting compounds.

Bubble-free: Evacuation made easy – for bubble-free potting results in a few minutes

  • The Bubble-free kit comes as a aluminium desiccator with polycarbonate lid, manometer and vacuum pump.
  • The transparent lid allows oberservation of the degassing process.
  • Quantities of > 500 g material can be evacuated in one step.

Sealing mastic EH 13.271

  • Solvent-free paste for sealing jobs in electronics and electrical engineering
  • self-adhesive and permelastic

Adhesion Promoters EH 13.950 series

  • Adhesion promoters for ELPECAST casting compounds based on epoxy / polyurethane resins

Adhesion Promoter G 4660

  • adhesion promoter for Wepesil casting compounds

Mould Release Agent EH 13.650

  • solvent-free, silicone- and grease-free
  • auxiliary product in the processing of ELPECAST casting compounds based on epoxy / polyurethane resins
  • for pre-treating the surfaces to be potted; after curing, the potting can be removed from the mould easily and without residue

Accelerating Agents B 4400 / B 4402

  • Accelerating agents for Wepuran casting compounds
  • shorten the curing time and pot life, thus recommended for mixing and dosing equipment

Cleaning Agent R 13.780

  • For cleaning workplace and tools
  • quick and thorough cleaning effect

Plastic cleaner HP 5402 / Special cloth

  • For cleaning the “Bubble-free basic” desiccator
  • gentle cleaning even of very dirty surfaces soiled with casting compound
  • high quality cotton cloth, soft and fluff-free, hard-wearing, absorbent

Conductive ink EH 13.344

  • Applied as a coating on the inside of casings and packagings it prevents and diverts static charges
  • application by brushing or spraying
  • dries at room temperature
  • auxiliary product recommended: Cleaning agent R 5817
